One Set Fully Automatic Toilet Paper Roller Machine And Kitchen Towel Machine
Machine Features
This machine is used for making toilet paper roll and kitchen towel paper, adopt advanced PLC technology,variable speed adjustment,electronic braking,and touch button multimenu type LCD screen operation control panel.Also the machine is newly added coreless roller shaped rewinding system.It’s adopt PLC wind pipe-shaped new technology.It’s no need to put core or stainless sheel pipe It’s full upgrade the whole machine.
Adopts international advanced PLC programmable controlling technique,man-machine interface operation,data set and parametric fault shows on touch screen
Machine Main Technical Parameter
| Total Power | Variable frequency speed control 7.5-15KW (depends on model and configuration) |
| Pneumatic System | 3HP Air Compressor,Minimum Pressure: 5kg/cm 2Pa (provide by user) |
| Jumbo Roll Max Width | 2000mm(Other size can be specified) |
| Jumbo Roll Diameter | 1100mm(Other size can be specified) |
| Jumbo Roll Inner Diameter | 76.2mm |
| Finish Product Diameter | Φ80-φ140mm |
| Finish product Inner Diameter | φ38-φ48mm |
| Perforation Distance | 100-150mm |
| Proforation Speed | 0-180m/min |
| Parameter Set | HMI,Touch Screen |
| Programme Controller | Delta Programmable Controller(Other brand optional) |
| Unwinding Transmission | Frequency Stepless Speed Regulation |
| Rewinding Unit | With Core or Coreless |
| Dimension | 7800X3000X1720mm |
| Weight | 3500~4500kg |
FAQ
Q: Can you provide the installation videos?
A: Yes, we will provide.
Q: What's the production time?
A: Generally it is 40-60 working days, it depends on your customized requirements.
Q: How long is your warranty?
A: One year of the machine, wearing parts not included.
Q: Can your company do customized machine?
A: Yes we can. We have 3 experienced engineers to support customized designs.
Q: How about your after-sales services?
A: We offer online instructions or onsite if needed.
